A-Frame Wall Bracer Installation

Install the Adventure Wagon A-Frame Wall Bracer system in a Ford Transit HR Long, including positioning the bracers, drilling mounting points, setting Rivnuts, and preparing the walls for L-track and panels.

We have modified how the wall bracers get installed. Please see our additional notes:

• If your ceiling braces (ribs) are not aligned with our centering tool, refer to the video guide below for how to measure and center your ceiling Speed Struts yourself.
• We are no longer using magnets to align the wall bracers. Instead, we use set screws included with your kit.
• If you've used self-tapping set screws to temporarily hold the wall track in place, please remove them once the track is fastened to ensure the L-Track lays flat against the wall bracer.
• Be careful when drilling vertical wall bracer holes that you do not accidentally clip the wiring harness. To avoid this, you can temporarily pull out the electrical harness.
• Do not install your upper wall Thinsulate insulation until after your wiring chase is installed to avoid leaving shavings in the insulation.
